Tiny house on a trailer
. 7000 lb trailer 16 ft long
. Two 3500 lb axles
. 2x4 and 2x3 wood frame construction
. 2 inch styrofoam board insulation in floor walls and ceiling...
. metal roof
. 24 inch solid wood front door
. 20 x 17 inch kitchen sink
. Two burner propane stovetop
. Small cube microwave
. Two fixed glass front windows
. One single hung bathroom window
. Bathroom ceiling fan
. 15 amp service panel (can be upgraded, wired currently as 15 amps... panel
is 70 amp panel)
. Propane fired instant hot water
. Metal barrel shower stall
. Composting toilet (with urine diverter)
. Twin bed (murphy style fold down)
. 5 ft. folding desk/dining table
. Provisions made for but buyer must purchase, a small wood burning stove or propane
fired heater (chimney and cap included but not installed)
. Ample kitchen storage
. Clothes hanging closet with rod
. Utility closet below clothes closet (could be for linens or folded clothes)
. Large built-in vanity cabinet for all your bathroom stuff
. Under “couch area” storage
. Above couch cabinet for additional storage
. Under counter refrigerator with freezer compartment
. Metal bar on rear to mount small deck area off front door
. Laminate countertops
. Circular shower curtain rod
. Low wattage LED lighting throughout (less than 50 watts total indoor lighting
and it’s bright !)
. Decor switches and outlets all rated for 110v AC
. 3 switched outlets in attic for possible exterior lighting or exhaust fans, or
. 5 shelves 7.5 inches deep for storage but also ladder to access attic area if
. Pine tongue and groove wall siding and ceilings throughout interior
. Laminate wood flooring front to back
. Area for couch seating when bed is folded up
. Propane regulator for hot instant hot water heater, and separate one for stove
. Cold water hose inlet for city water pressure
. 110v AC 15 amp power inlet
. Rubber flashing from bottom up to 18 inches
. Standard house wrap from 18in. to top of walls
. 1kw solar panel system with 450 amp hour battery storage
We have new videos all the time so keep an eye on this page or just subscribe to
the Tiny Sanctuary Youtube page
Solar panel system is excluded from standard options
Was $24,500 now $17,900
Tiny Sanctuary was just sold on 12/19/16... On to the next project which will be
most likely be “Tiny2”, a smaller version at only 12 feet long...
Click here to go to the YouTube page for all the tiny sanctuary videos...
Page 1 2 3
And a general lowering of the price because it’s paid for itself already... “Ah the
joy of tiny living” !
All the information for this build will remain here for the time being as reference
People keep asking so... Click here for a link to my refrigerator...
People keep asking so... Click here for a link to my instant hot water solution...
This section is unavailable at the moment but will be active again when I start the
next tiny house...
TINY SANCTUARY FOR SALE !
